In addition, the screen display can show one of the following eight types of data in the 18 lines of variable
display:
Program Displays:
The PROGRAM DISPLAY is used to show your program while in either MEM, EDIT, or MDI modes.
Position Display:
The POSITION DISPLAY is used to select the X, Y, Z, or A axes positions in any of several coordinate sys-
tems. The PAGE UP and PAGE DOWN keys select between these.
Offsets Display:
The OFFSETS DISPLAY is used to enter and display tool length offsets, tool radius offsets, and work offsets.
The PAGE UP and PAGE DOWN keys will scroll between these.
Current Commands Display:
The CURRENT COMMANDS DISPLAY is used to display the Program Command Check, the Current Com-
mands, Running Timers, Tool Life Timers, Tool Load Monitor, and Axis Load Monitor. The PAGE UP and PAGE
DOWN keys select between these.
Alarms / Messages Displays:
The ALARMS/MESSAGES DISPLAY is used to display alarms and to enter and display user messages. The
second push of the ALARM button will select messages display. The CURSOR up and down buttons will
display additional alarms if there is more than will fit on one page.
Parameters / Diagnostics Displays:
The PARAMETERS DISPLAY shows all of the machine dependent control parameters and the Diagnostic data.
The second push of the PARAM / DGNOS button will select the diagnostic display. The PAGE UP, PAGE
DOWN, up and down cursor keys, and the jog handle can be used to scroll through the parameter display
screens in the control. The left and right cursor keys are used to scroll through the bits in a single parameter.
Settings / Graphics Displays:
The SETTINGS DISPLAY is used to display and change user controlled parameters. The second push of the
SETNG / GRAPH button will select the Graphics display.
Help / Calculator Displays:
The HELP DISPLAY shows a mini-manual on the CRT along with a directory of available help information.
Each alphabet button will select a different topic within the HELP display. The second push of the HELP
button will select the Calculator display. The PAGE UP and PAGE DOWN buttons will select different calcula-
tor functions.
