277
PARAMETERS
June 1999
96-8000
Parameter 56 A DEAD ZONE
See Parameter 14 for description.
Parameters 57 through 128 are used to control other machine dependent functions. They are:
Parameter 57 COMMON SWITCH 1
Parameter 57 is a collection of general purpose single bit flags used to turn some
functions on and off. The left and right cursor arrows are used to select the function being
changed. All values are 0 or 1 only. The function names are:
REV CRANK Reverses direction of jog handle.
DISABLE T.C. Disables tool changer operations.
DISABLE G.B. Disables gear box functions.
POF AT E-STP Stops spindle then turns the power off at EMERGENCY STOP
RIGID TAP Indicates hardware option for rigid tap.
REV SPIN ENC Reverses sense direction of spindle encoder.
REPT RIG TAP Selects repeatable rigid tapping.
EX ST MD CHG Selects exact stop in moves when mode changes.
SAFETY CIRC. This enables safety hardware, if machine is so equipped.
SP DR LIN AC Selects linear deceleration for rigid tapping. 0 is quadratic.
PH LOSS DET When enabled, will detect a phase loss.
COOLANT SPGT Enables coolant spigot control and display.
OVER T IS NC Selects control over temp sensor as N.C.
SKIP OVERSHT Causes Skip (G31) to act like Fanuc and overshoot sense point.
NONINV SP ST Non-inverted spindle stopped status.
SP LOAD MONI Spindle load monitor option is enabled.
SP TEMP MONI Spindle temperature monitor option is enabled.
ENA ROT & SC Enables rotation and scaling.
ENABLE DNC Enables DNC selection from MDI.
ENABLE BGEDT Enables BACKGROUND EDIT mode.
ENA GRND FLT Enables ground fault detector.
M19 SPND ORT This bit makes the P and R codes a protected feature which can only
be enabled with an unlock code. The unlock code will be printed on
the parameter listing of all new machines. If this bit is set to 0, an
M19 will orient the spindle to 0 degrees regardless of the value of any
P or R code in the same block. If this is set to 1, a P code in the
block will cause the spindle to be oriented to the specified angle such
as P180. Alternately, a decimal R code can be used, such as
R180.53. Note that the P and R codes only work on a vector drive
machine.
