Haas VF Series Operator's Manual

94 96-8000
June 1999
OPERATION
To the right side of the jog keys are three keys to control the optional automatic spigots. If the spigot
is enabled with Parameter 57, these keys perform the following functions:
CLNT UP Pressing this key positions the coolant stream direction one position higher, if
possible.
CLNT DOWN Pressing this key positions the coolant stream direction one position lower, if
possible.
AUX CLNT Pressing this key while in MDI mode will turn on the Through the Spindle Coolant
system, and pressing it again will shut off the system.
OVERRIDES: The overrides are at the lower left of the control panel. They give the user the
ability to override the speed of rapid traverse motion, as well as programmed feeds
and spindle speeds.
HANDLE CONTROLAllows jog handle to be used to control feedrate in +/-1% increments (from 0 to
FEEDRATE 999%).
-10 Decreases current feed rate by 10% (from 10 to 200%).
100% Sets control feed rate to programmed feed rate.
+10 Increases current feed rate by 10% (from 10 to 200%).
HANDLE CONTROL Allows jog handle to be used to control spindle speed in +-1% increments (from 0
SPINDLE to 999%).
-10 Decreases current spindle speed by 10% (from 10 to 150%).
100% Sets spindle speed to programmed speed.
+10 Increases current spindle speed by 10% (from 10 to 150%).
CW Starts the spindle in the clockwise direction. Except CE machines.
STOP Stops the spindle.
CCW Starts the spindle in the counterclockwise direction.
5% RAPID Limits rapid traverse to 5 percent of maximum.
25% RAPID Limits rapid traverse to 25 percent of maximum.
50% RAPID Limits rapid traverse to 50 percent of maximum.
100% RAPID Allows rapid traverse to feed at its maximum.

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
