172 THE HASSELBLAD MANUAL
Figure 9-11 201 camera model. The 201
camera is distinguished mainly by the ASA
dial for dedicated fl ash. Above the battery
compartment is the lock for the shutter
speed ring.
Figure 9-12 201 battery check. The
condition of the 201 battery is checked
by placing the battery symbol on the
shutter speed ring opposite the index.
Figure 9-13 Mirror motion on 2000/2003 cameras. (1) Change the mirror motion by turning
the slotted disc with a coin. Turn the disc to 1 if the mirror is to return when the shutter is
recocked, to 2 for instant return operation, or to 0 if the mirror is to be permanently locked
up. (2) To change the mirror motion on 2003FCW models, remove the crank or motor, pull
out the ring (B), and turn the shaft to 1, 2, or 3.
