Heraeus Electro-Nite CasTemp Wireless - Data Formats Definition; Heat Number Identification; Time Synchronisation Procedure

5 June 2020 CasTemp Wireless including CasTemp Superheat Page 22
9.4.3.5.2 ASCII
Field name
description
Data format
Message header
Id
4
1 Char
DataCount
5
2 Chars
Payload
SH value
The limit at which the customer wants to be
warned. This is not an absolute value, but an
offset added to the current LT temperature
4 Chars
Temperature unit
Represents the temperature unit of the SH
value.
TempUnit
Example
SH value = 15
Temperature unit = Celsius
Field
Id
DataCount
SH value
Temperature Unit
Char value
4
05
0015
C
Byte index
1
[2-3]
[4-7]
8
9.4.3.6 Ready to Cast
Ready to Cast is a telegram which tells the software that the tundish is in casting position. This allows
a CasTip measurement to be taken and displayed on screen.
9.4.3.6.1 Byte
Field name
description
Data format
Message header
Id
5
Byte
DataCount
1
UShort
Payload
Status
Indicates if the plant is ready to cast
Byte
1: Ready
2: Not ready
Example
Status = Not Ready
Field
Id
DataCount
Status
Hex value
{05}
{00}{01}
{02}
Byte index
1
[2-3]
4
9.4.3.6.2 ASCII
Field name
description
Data format
Message header
Id
5
1 Char
DataCount
1
2 Chars
Payload
Status
Indicates if the plant is ready to cast
1 Char
1: Ready
2: Not ready
Example
Status = Not Ready
Field
Id
DataCount
Status
Char value
5
01
2
Byte index
1
[2-3]
4
