Heraeus Electro-Nite CasTemp Wireless - Data Formats Definition

5 June 2020 CasTemp Wireless including CasTemp Superheat Page 21
9.4.3.4.1 Byte
Field name
description
Data format
Message header
Id
3
Byte
DataCount
4
UShort
Payload
Remaining minutes
until ladle empty
The number of minutes until the ladle is
empty.
Int32
Example
Remaining minutes until ladle empty = 75
Field
Id
DataCount
Remaining minutes until ladle empty
Hex value
{03}
{00}{04}
{00}{00}{00}{4B}
Byte index
1
[2-3]
[4-7]
9.4.3.4.2 ASCII
Field name
description
Data format
Message header
Id
3
1 Char
DataCount
4
2 Chars
Payload
Remaining minutes
until ladle empty
The number of minutes until the ladle is
empty.
4 Chars
Example
Remaining minutes until ladle empty = 75
Field
Id
DataCount
Remaining minutes until ladle empty
Char value
3
04
0075
Byte index
1
[2-3]
[4-7]
9.4.3.5 Critical SuperHeat Limit
Critical Superheat Limit is the amount of Superheat the customer would like to display graphically
above the measured liquidus. I.e. if the customer wanted 10°C Superheat limit and CasTip measured
liquidus at 1500°C the software would graphically display 1510°C as the Superheat limit.
9.4.3.5.1 Byte
Field name
description
Data format
Message header
Id
4
Byte
DataCount
5
UShort
Payload
SH value
The limit at which the customer wants to be
warned. This is not an absolute value, but an
offset added to the current LT temperature
Int32
Temperature unit
Represents the temperature unit of the SH
value.
TempUnit
Example
SH value = 15
Temperature unit = Celsius
Field
Id
DataCount
SH value
Temperature Unit
Hex value
{04}
{00}{05}
{00}{00}{00}{0F}
{43}
Byte index
1
[2-3]
[4-7]
8
