4.28 Stow and Go® Foot Section Wireform
Chapter 4: Procedures
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 4 - 47
4
3. Raise the foot section to the full up position.
Failure to unplug the bed can cause personal injury or equipment damage.
4. Unplug the bed from its power source.
5. Put the siderail lockout switch at the head end of the bed in the locked position.
6. Remove the placenta basin (A) from the foot section (B) (see Figure 4-32 on page 4-48).
7. Remove the foot section (B).
8. Remove the two screws (C) that attach the wireform (D) to the foot section weldment (E).
9. Remove the two nuts (F) from the bolts (G).
10. Support the weight of the wireform (D) with one hand.
11. Remove one bolt (G).
12. Remove the other bolt (G).
13. Remove the wireform (D) from the bed.
REPLACEMENT
1. Do the removal procedure in reverse order.
2. Do the “Function Checks” on page 2-5.
