4.36 Oxygen Tank Holder (P27605)
Chapter 4: Procedures
4 - 60 Affinity® Four Birthing Bed Service Manual (195826 REV 2)
4.36 Oxygen Tank Holder (P27605)
Tools: None
INSTALLATION
1. Install the mounting bar vertically into a mounting socket at the head end of the frame.
2. Put one E-size oxygen tank in the holder.
3. Tighten the holder thumbscrew.
NOTE:
The thumbscrew keeps the oxygen tank from turning in the holder.
REMOVAL
1. Loosen the thumbscrew that holds the tank securely in the holder.
2. Lift the tank out of the holder.
3. Lift up on the tank holder, and remove it from the mounting sockets.
4.37 Telescoping Calf Supports (P35745A) or Telescoping Full Leg Supports
(P7634C)
Tools: None
INSTALLATION
1. Set the brake/steer pedal to the brake position.
2. Make sure that the bed is out of the Trend-Like position.
3. Use the Foot Up/Foot Down control to put the foot section in a mid-height position.
4. Put the telescoping supports (A) into position and insert them into the mounting post (B) (see
Figure 4-40 on page 4-61).
