4.32 Line Manager
Chapter 4: Procedures
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 4 - 55
4
REPLACEMENT
1. Do the removal procedure in reverse order. As you replace components, make sure of these:
a. The brake/steer strip (straight metal strap – V) and the brake strip (bent metal strap – K) are
correctly assembled on their respective sides.
b. The brake strips (K and V) are correctly attached to their cam pivots.
c. The brake and steer caster or the brake caster is adjusted correctly. See “Brake and Steer Caster
Adjustment” on page 4-52 and “Brake Caster Adjustment” on page 4-53.
2. Make sure that the brake and steer functions operate correctly.
3. Do the “Function Checks” on page 2-5.
4.32 Line Manager
Tools: 7/16” wrench 1/2” wrench, socket and ratchet
The line manager is only compatible with the standard headboard. It is not compatible with the Liberty
Hill™ and Freedom Hill™ headboards.
REMOVAL
1. Set the brakes.
2. Raise the head section to 45°.
Failure to unplug the bed could cause injury or equipment damage.
3. Unplug the bed.
4. Put the siderail lockout switch at the head end of the bed in the locked position.
5. Do as follows for each side:
a. Remove the nut (A) that attaches the line manager (B) to the bracket (C) (see Figure 4-36 on
page 4-56).
b. Remove the two nuts (D) and washers (E) from the bolts (F).
c. Remove the bolts (F) and bracket (C) from the bed frame (G).
