4.29 Ramps—Stow and Go® Feature
Chapter 4: Procedures
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 4 - 49
4
4.29 Ramps—Stow and Go® Feature
Tools: 1/8” hex wrench or hex bit socket
1/2” wrench 1/2” hex wrench Ratchet
REMOVAL
1. Make sure the brakes are set.
2. Raise the bed to the highest position.
Failure to unplug the bed could cause injury or equipment damage.
3. Unplug the bed.
4. Put the siderail lockout switch at the head end of the bed in the locked position.
5. Remove the placenta basin (A) (see Figure 4-33 on page 4-50).
6. Stow the foot section (B).
7. Loosen, do not remove, the setscrew (C).
8. Remove the screws (D) that attach the wire guide (E) to the ramps (H).
9. Remove the bolts (F) and nuts (G) from the ramps (H).
10. Remove the ramps (H) from the lock blocks (I).
11. Remove the ramps (H) from the bed.
REPLACEMENT
1. Do the removal procedure in reverse order.
a. Use the new setscrews (C) supplied with the ramps (H).
b. Tighten the setscrews (C) until they do not move.
c. Pull on the wireform (J), and make sure it stays inside the ramps (H).
d. Make sure that the bushings (K) are installed in the lower part of the ramps (H).
2. Do the “Function Checks” on page 2-4.
