Hill-Rom Affinity P3700E - Trend-Like Position Functional Check; Head System Functional Check

Function Checks
Chapter 2: Troubleshooting
2 - 6 Affinity® Four Birthing Bed Service Manual (195826 REV 2)
3. Momentarily press the Bed Down control. The bed lowers.
Yes No
Go to RAP 2.4 on page 2-13.
4. Press the Bed Up control and then the Bed Down control. The hilow motor is free of excessive noise
or any mechanical binding/grinding.
Yes No
Go to RAP 2.6 on page 2-15.
5. Press the Bed Up control and then the Bed Down control to raise, and then lower the sleep surface.
The bed sleep surface stops and does not drift downward or coast.
Yes No
Go to RAP 2.6 on page 2-15.
6. Press the Bed Down control to fully lower the bed to the low position.
• If the bed has the Lift-off Foot Section installed, the top of the seat section is 18.5 to 19.5 inches
(47.0 to 49.5 cm) above the floor.
• If the bed has the Stow and Go® Foot Section installed, the top of the seat section is 19.0 to 20.0
inches (48.25 to 50.8 cm) above the floor
Yes No
Adjust the hilow limit switch (LBD) (see Procedure 4.5 on page 4-9). If this solves the
problem, go to “Final Actions” on page 2-9. Otherwise, contact Hill-Rom Technical
Support.
TREND-LIKE POSITION FUNCTIONAL CHECK
1. Put the bed into a mid-height position. Activate the Trend-Like position release handle at the head
end of the bed, and put the bed in and out of the Trend-Like position. The bed goes in and out of
Trend-Like position smoothly, and the sleep surface is attached when the handle is released:
Yes No
Adjust the Trend-Like position sensing switch (see Procedure 4.11 on page 4-21). If
this solves the problem, go to “Final Actions” on page 2-9. Otherwise, contact
Hill-Rom Technical Support.
HEAD SYSTEM FUNCTIONAL CHECK
1. Make sure that the sleep surface is level, and put the bed in the following positions:
• Put the bed in a mid-height position with the hilow function.
• Put the head section in a mid-height position with the head function.
2. Momentarily activate the head up switch. The head section rises.
Yes No
Go to RAP 2.6 on page 2-15.
3. Momentarily activate the head down switch. The head section lowers.
Yes No
Go to RAP 2.6 on page 2-15.
