Hill-Rom Affinity P3700E - Line Manager

Line Manager
Chapter 5: Parts List
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 5 - 39
5
LINE MANAGER
Figure 5-14. Line Manager
Table 5-14. Line Manager
Item Number Part Number
Quantity
a
a. Quantities shown are for each line manager.
1 9001624H 2 Bolt
2 831 2 Nut
3 127357 2 Washer
4 16527001 1 Weldment, rh
16527002 1 Weldment, lh
5 146287 1 Flex arm
6 152908 1 Nut
Description
