Headboard—Wood Style
Chapter 5: Parts List
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 5 - 37
5
HEADBOARD—WOOD STYLE
Figure 5-12. Headboard—Wood Style
Table 5-12.
Item Number Part Number Quantity Description
1 43878 2 Screw, button hd Torx®
2 37664 2 Clip, IV
3 31773 10 Screw
4 40995 1 Handle weldment, headboard
165456 1 Weldment, headboard, w/o handles
5 42600 2 Plug
6 42588 2 Grip, handle, foam
7 41114 1 Headboard, wood
112769 1 Headboard, wood—Liberty Hill™
112770 1 Headboard, wood—Freedom Hill™
Not shown 169548 1 Label, Do not push, wood headboards w/o
handles
