4.7 CPR Release Adjustment
Chapter 4: Procedures
4 - 14 Affinity® Four Birthing Bed Service Manual (195826 REV 2)
REPLACEMENT
1. Do the removal procedure in reverse order. As you replace components, make sure of these:
a. Make sure the CPR cable routing is correct and free from binding.
b. Make sure all cable ties, clamps, and connectors are correctly installed.
2. Do the “Function Checks” on page 2-5.
ADJUSTMENT
To adjust the CPR function, see Procedure 4.7 on page 4-14.
4.7 CPR Release Adjustment
Tools: Adjustable wrench
ADJUSTMENT
1. Set the brake/steer pedal to the brake position.
2. Make sure the bed is out of the Trend-Like position.
3. Put the bed in a mid-height position.
4. Raise the head section to its highest position.
5. Make sure the siderails are in the up position.
Failure to unplug the bed could cause injury or equipment damage.
6. Unplug the bed from its power source.
7. Put the siderail lockout switch at the head end of the bed in the locked position.
8. Remove the top motor cover (see Procedure 4.1 on page 4-3).
9. Make sure the CPR cables (A) are routed inside the head section weldment (B) (see Figure 4-8 on
page 4-15).
