Hill-Rom Affinity P3700E - Push Handles

Push Handles
Chapter 5: Parts List
5 - 38 Affinity® Four Birthing Bed Service Manual (195826 REV 2)
PUSH HANDLES
Figure 5-13. Push Handles
Table 5-13. Push Handles
Item Number Part Number
Quantity
a
a. Quantities shown are for each handle.
1 68351 1 Switch housing
2 163841 2 Screw
3 15909101 1 Grip, lh
15909102 1 Grip, lh
4 16763401 1 Handle assembly, lh
16763402 1 Handle assembly, rh
5 4435 2 Nut
6 68302 1 Screw
7 68301 1 Coupler shield
8 161567 1 Tube, pivot
9 62634 1 Roll pin
10 49521 1 Screw
Description
