Main Frame Module—(Sheet 1 of 2)
Chapter 5: Parts List
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 5 - 9
5
Table 5-2. Main Frame Module—(Sheet 1 of 2)
Item Number Part Number Quantity Description
1 6391648 1 Top cover
2 41250 1 Headboard bushing, oval
3 71993 7 Screw
4 41078 1 Headboard bushing, round
5 67048 1 Shroud
6 10595 2 Screw
7 163860 2 Bushing
8 4715301 2 Bumper pin
9 47219 2 Bumper
10 6314304 4 Clevis pin
11 4540 8 Washer
12 7037606 2 Nut
13 192715 2 Lever arm
14 61615 8 Retain, rue
15 70375 2 Screw
16 193029 2 Trendelenburg follower
17 33680 2 Nut
18 9025916 2 Shoulder bolt
19 165540 2 Screw
20 9685 4 Roll pin
21 41252 2 Trendelenburg gas head
22 19512 2 Limit switch
23 15463 2 Bolt
24 41253 1 Trendelenburg limit switch bracket
25 20605 4 Locknut
26 34401 2 Spacer
27 34402 4 Screw
28 43056 2 Extension spring
29 142320 2 Trendelenburg gas spring
30 43059 2 Retaining ring
31 190934 2 Trendelenburg handle weldment
32 192158 2 Trendelenburg handle foam (“S” shape)
33 46416 2 Bushing
34 40915 1 Trendelenburg handle hex bar
35 41089 4 Foot section pin
36 43039 2 Seat pivot bracket
