Main Frame Module—(Sheet 2 of 2)
Chapter 5: Parts List
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 5 - 13
5
Table 5-3. Main Frame Module—(Sheet 2 of 2)
Item Number Part Number Quantity Description
1
393 4 Screw
2 41272 1 Shroud, seat side, rh
3 41023 4 Trend pivot block
4 27509 4 Roll pin
5 41037 4 Bushing plate, foot section
6 9016128 8 Cap screw
7 41036 4 Bushing
8 179203 3 Pin, clevis
9 61615 8 Rue ring
10 63927 1 Drive, head
11 191575 1 Drive, hilow, foot
12 61653 2 Clevis pin
13 6393348 1 Foot section pivot weldment
14 6314306 1 Clevis pin
15 41263 1 Foot section link bar
16 48868 2 Clevis pin
17
6161501 7 Rue ring
18 65915 1 Extension tube, foot drive
19 41273 1 Shroud, seat side, lh
20 41112 1 Yoke casting
21 40937 2 Post and key
22 65967 4 Clevis pin
23 41089 4 Foot section pin
24 19678 4 Truarc ring
25 48874 4 Foot section lift arm
26 4886801 1 Clevis pin
27 9026301 20 Self lubricating bearing
28 43878 4 Screw
29 41413 1 Front shroud
30 4677248 1 Placenta basin
31 6398848 1 Bottom cover weldment
32 43878 17 Screw button head Torx®
