Foot Support Module
Chapter 5: Parts List
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 5 - 15
5
Table 5-4. Foot Support Module
Item Number Part Number Quantity Description
Not shown 148944 1 Foot support, complete, lh
Not shown 148945 1 Foot support, complete, rh
1 155066 2 Foot support handle
2 69391 6 Screw
3 43394 2 Clevis pin
4 60086 2 Screw
5 65829 2 Toe boot
6 142961 2 Release handle, vinyl dipped cap
7 66152 2 Gas spring
8 4921 2 Screw (only used on beds without calf support)
9 6604202 2 Clevis pin
10 61615 2 Rue ring
11 35325 6 E-ring
12 66966 2 Set screw
13 65700 4 Bushing
14 65800 2 Cable, foot tilt
15 65799 2 Cable, foot abduction
16 19124 2 Wire tie
17 66430 2 Washer, plastic
18 65964 2 Snap ring
19 155065 2 Heel cup
20 142825 2 Clamp, bellows
21 68112 2 Hole plug
22 142959 1 Foot rest weldment, lh
23 6572401 1 Cam post weldment, lh
24 6580101 1 Mechlok®, foot left, lh
25 142958 1 Bellows, foot support, lh
26 142377 1 Release handle weldment, lh
27 6696801 1 Mechlok®, foot tilt, lh
28 142960 1 Foot rest weldment, rh
29 6572402 1 Cam post weldment, rh
30 6580102 1 Mechlok®, foot lift, rh
31 143010 1 Bellows, foot support, rh
32 143225 1 Release handle weldment, rh
33 6696502 1 Mechlok®, foot tilt, rh
34 145103 1 Kit, bellows assembly, rh (includes 4, 20, and
32)
