Base Module (Sheet 1 of 2)
Chapter 5: Parts List
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 5 - 21
5
Table 5-6. Base Module (Sheet 1 of 2)
Item Number Part Number Quantity Description
1 152317 2 Top, orange pedal
2 70781 2 Top, green pedal
3 152316 2 Bottom, orange pedal
4 70780 2 Bottom, green pedal
5 165566 1 Brake link, foot, rh
6 152893 2 Pedal weldment
7 142628 2 Brake cam
8 43951 4 Pin
9 142639 2 Flanged bushing
10 143966 2 Brake pedal support
11 434602 1 End cap cross tube, rh
12 165567 2 Brake link, head
13 41308 4 End cap
14 90477 4 Shoulder bolt
15 4708501 4 Base boss cap
16 9026312 4 DU bushing
17 44352 6 Cotter pin
18 757 4 Clevis pin
19 43878 16 Screw
20 4126948 4 Leg cover
21 158890 8 Retaining ring
22 165571 8 Spacer, rocker arm
23 32425 4 Bolt
24 34715 4 Rover arm
25 165568 4 Groove pin, rocker arm
26 32572 4 Screw
27 43030 4 Washer
28 40980301 4 Washer
29 165565 1 Brake link, foot, lh
30 4394601 1 End cap cross tube, lh
31 43957 1 Detent housing place
32 142638 1 Spring
33 40827 2 Double sided tape
34 43949 1 Detent plunger
35 152284 1 Detent mechanism housing
152801S 1 Detent mechanism assembly
