Base Module (Sheet 2 of 2)
Chapter 5: Parts List
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 5 - 25
5
Table 5-7. Base Module (Sheet 2 of 2)
Item Number Part Number Quantity Description
1 6314308 1 Clevis pin
2 191575 1 Bed hilow drive
3 44352 2 Cotter pin
4 179203 1 Clevis pin
5 179206 1 Intermediate frame weldment
6 68188 4 Bushing
7 40827 4 Double sided tape
8 67223 1 Lift arm weldment
9 6314304 2 Clevis pin
10 9026304 4 DU bushing
11 63962 2 Link, hilow
12 66039 4 Nut
13 61615 4 Rue ring
14 143032 1 Lift arm follower
15 127368 8 Screw, cap
16 6818948 4 Retaining strap
17 27509 4 Roll pin
18 179192 2 Bushing, motor mount
19 72360 1 Bushing
