Sleep Deck Module
Chapter 5: Parts List
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 5 - 27
5
Table 5-8. Sleep Deck Module
Item Number Part Number Quantity Description
1 193051 1 Weldment, head section
2 4106148 1 Deck, head
3 4105948 1 V seat panel
4106048 1 U seat panel
4 67088 2 Slide
5 6392148 1 Weldment, seat section
6 6393901PL 1 Weldment, CPR handle, lh
7 35308 2 Washer, finish, 0.203, 0.81, 0.19, nyl
8 6393902 PL 1 Weldment, CPR handle, rh
9 6394801PL 1 Weldment, lh handle, labor grip
10 41344 2 Rivet, barb, 0.250, 0.185, fl, nyl
11 67393802 1 CPR handle, right
12 159215 13 Washer, flat, 7.1, 19.3, 1.6
13 35326 3 Retain, ering, 0.292, 0.035, ph
14 65986 13 Bolt, roll, trus, tx, 0.250-20,0.75
15 903390 4 Screw, mach, rnd, ph, 10-24, 1.0
16 6393801 1 CPR handle left
17 40817 2 Retain, ring, ext, 0.887, 0.042
18 42617 2 Washer, lk, 1 wv, 0.265, 0.49, 0.008, SS
19 41047 4 Washer, fl, 0.530, 0.750, 0.062, nyl
20 43878 8 Screw, mach, pan, ph, 10-32, 0.422
21 43552 2 Retain, ring, ext, 0.461, 0.035, ph
22 9033810 2 Screw, shldr, rnd, hxst, 10-24, 1.0
23 6394802P 1 Weldment, rh handle, labor grip
24 659660148 1 Weldment, labor grip, lh
25 9026006 2 Bolt, shldr, hxst, 0.375-16, 0.375
26 164284 2 Nut, nyloc, 8-32, 0.2
27 40811 2 Pin, lk, 0.500, 2.625, ss
28 40812 2 Spring
29 659660248 1 Weldment, labor grip, rh
30 6314306 1 Pin, clv, 0.371, 1.857, cs
31 61615 1 Retain, rue, 3/8, 0.054
32 9026307 2 Bushing, brg, 0.593, 0.250, 0.500, stl
33 409801 2 Stud, snp, pin, 8-32, 0.28
34 4106848 1 Splash channel
35 62919 2 Vinyl dipped cap release handle
