Foot Section
Chapter 5: Parts List
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 5 - 31
5
Table 5-9. Foot Section
Item Number Part Number Quantity Description
1 42575 1 V-cut wireform
2 42576 1 U-cut wireform
3 142631 1 Lift handle, lh
4 142632 1 Lift handle, rh
5 49521 4 Screw, 1/4 - 20 x 5/8”, K-25
6 185798 1 Latch weldment, lh
7 185799 1 Latch weldment, rh
8 9001828 4 Screw
9 1012 14 Washer
10 4435 4 Locknut
11 142642 1 Foot latch, lh
12 142641 1 Foot latch, rh
13 4257401 6 Screw
14 145159 1 Perineal stand, U-cut
15 144069 1 Perineal stand, V-cut
16 9001836 2 Screw
17 45823 2 Nut, locking, 1/4-20
18 158840 1 Foot section weldment
19 46765 2 Plug
20 146075 1 Lift-off V-cut foot section
21 146076 1 Lift-off U-cut foot section
22 161329 1 Foot section
23 142772 1 Placenta basin
24 143183 1 Lock block, rh
25 142720 1 Lock block, lh
26 144184 4 Screw (long)
27 9016114 2 Screw (short)
28 9025908 2 Shoulder screw
29 60619 2 Nut, nylock, 5/16 - 18
30 145105 2 Slide guide assembly
31 144106 2 Spring retainer
32 43878 4 Machine screw, 10-32
33 160312 1 Ramp, lh
34 160323 1 Ramp, rh
35 145287 1 Ramp guide, rh
36 145275 1 Ramp guide, lh
