Electronics Module (Sheet 1 of 2)
Chapter 5: Parts List
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 5 - 45
5
Table 5-17. Electronics Module (Sheet 1 of 2)
Item Number Part Number Quantity Description
1 6342201 1 Power cord, detachable 110V
6342202 1 Power cord, detachable 220V, Australia/New
Zealand
6342203 1 Power cord, Continental Europe
6342204 1 Power cord, UK/Ireland
6342205 1 Power cord, Switzerland
6342206 1 Power cord, Denmark
6342211 1 Power cord, Japan
2 46015 2 Screw, bottom rail end cap
3 154444 1 Power entry module
4 4314317 2 Fuse, timelag, 4A, 125V AC, 5 mm x 20 mm
For use on beds with 120V AC wall power.
182100 2 Fuse, timelag, 2A, 250V AC, 5 mm x 20 mm,
high-breaking capacity
For use on beds with 230V AC wall power.
7061001 2 Fuse, timelag, 5A, 125V AC 5 mm x 20 mm
For use on beds with 100V AC wall power.
5 66230 1 Cable assembly, ground
6 49493 10 Screw, button hd Torx®
7 179083 1 Bottom motor mover
8 178294 1 Gasket, bottom motor cover (front)
178295 2 Gasket, bottom motor cover (side)
9 71993 8 Screw, bottom motor cover
10 9493 2 Screw, pendant bracket
11 179237 1 Pendant bracket
12 4142501S 1 Cable assembly, pendant control
13 183055 1 Night light P.C. board
184896 1 Night light cable
185346 1 Night light lens
14 186480 4 Standoff, P.C. board, nylon
15 4950816 2 Screw, 6-32, 1.0, tx
16 164284 2 Nut
17 4142301S 1 Cable assembly, Trendelenberg mechanical
limits
18 19124 2 Cable tie
19 4840501 2 Battery, lead acid, sealed, 12V, 7.2A
20 6583048 1 Bracket, battery hold-down
21 63945 1 Cable assembly, battery
To Next Page
