Electrical Cable Routing (Sheet 2 of 2)
Chapter 5: Parts List
Affinity® Four Birthing Bed Service Manual (195826 REV 2) 5 - 57
5
Table 5-22.
Item Number Part Number Quantity Description
1 6394201 1 Cable assembly, battery-to-battery
2 44125 1 Plug (used on 230V beds only)
3 44128 1 Lockwasher, serrated (used on 230V beds
only)
4 44126 1 Nut (used on 230V beds only)
5 44127 1 Washer—color code green/yellow (used on
2
30V beds only)
6 44464 1 Label, potential equalization (used on 230V
be
ds only)
7 63945 1 Cable assembly, battery
8 19124 2 Cable tie
9 43878 7 Screw, button hd Torx®
10 17292 6 Cable clamp
11 6642910S 1 Fuse, 10A, 32 V DC, automotive style
12 27873 1 Cable clamp (used prior to panel-mounted
pendan
t control cable connection only)
13 4142501S 1 Cable assembly, pendant control
14 10595 2 Screw, pan hd
Electrical Cable Routing (Sheet 2 of 2)
