Overview
20
4990851_002_00 – 2082262 – 2022-01-10
2025264 W302 Cable from the distributor board (sensor
connection to end position of leg section)
through the power chain to cable W506
(plug connection in right strut)
Chapter 13.2, page 93
2025266 W303 Cable from the distributor board (sensor
connection to zero position of back
section) through the power chain to
cable W507 (plug connection in right strut)
Chapter 13.2, page 93
2025273 W304 Cable from the distributor board
(operating sensor connection) through the
power chain to cable W508 (plug
connection in column head)
Chapter 13.2, page 93
2025263 W305 Cable from the longitudinal slide of the
motor through the power chain to cable
W401 (plug connection in column head)
Chapter 13.2, page 93
2025271 W306 Cable from the distributor board to the
IR circuit board at the foot end
Chapter 13.2, page 93
2072457 W320 Cable from the distributor board (hook
sensor connection) through the power
chain to cable W520 (plug connection in
right strut)
Chapter 13.2, page 93
2025245 W401 Cable from the main board (Main
Controller Unit) (connection of longitudinal
slide motor, motor for leg section hinge
and motor for back section hinge) to the
plug connection in the column head
Chapter 13.2, page 93
2025248 W402 Cable from the distributor board to the
main board (Main Controller Unit)
Chapter 13.2, page 93
2025249 W404 (protective
conductor)
Protective conductor from column head
(foot end) to Trendelenburg bracket
Chapter 13.2, page 93
2025275 W502 (sensor for
end position of
back section)
Cable from left back section hinge to cable
W202 (plug connection in strut)
Chapter 13.4, page 96
2056956 W503 (sensor in
end position of leg
section)
Cable from left leg section hinge to cable
W203 (plug connection in strut)
Chapter 13.3, page 94
2025272 W505 Cable from distributor board to IR circuit
board at head end
Chapter 13.2, page 93
2056959 W506 (sensor in
end position of leg
section)
Cable from right leg section hinge to cable
W302 (plug connection in strut)
Chapter 13.3, page 94
2056960 W507 (sensor in
zero position of
back section)
Cable from right back section hinge to
cable W303 (plug connection in strut)
Chapter 13.4, page 96
2057062 W508 (operating
sensor)
Cable from operating sensor to cable
W304 (plug connection in column head)
Chapter 13.5, page 98
2072262 W520 (hook
sensor)
Cable from hook sensor to cable W220
(plug connection in right strut) or to cable
W320 (plug connection in left strut)
Chapter 13.6, page 100
Material
number
Cable Cable routing Description
