Overview
4990851_002_00 – 2082262 – 2022-01-10 19
4.1 Cable overview
[9] Insertion aperture for the extension adapter
The extension adapter is available as an accessory from
Trumpf Medizin Systeme.
[10] Support block for extension adapter
The extension adapter is available as an accessory from
Trumpf Medizin Systeme.
[11] Control module connection socket in the IR housing
[12] Running gear
[13] Connecting pin for equipotential bonding conductor
[14] Connector socket for the mains cable
[15] Wheel
All 4 wheels can be turned around their own axis by 360°.
[16] Retractable feet (parking brake)
[17] Mains power cable
[18] Equipotential bonding conductor
[19] Head end of the operating table
[20] Foot end of the operating table
[21] Emergency release lever for running gear
[22] Switch for switching the operating table on/off
[23] Pad
[24] Column protection, 2-piece (cladding protection)
[25] Magnet
Material
number
Cable Cable routing Description
Tabletop
2025250 W201 Cable from the left motor for leg section
hinge and the left motor for back section
hinge through the power chain to cable
W401 (plug connection in the column
head)
Chapter 13.2, page 93
2025267 W202 Cable from the distributor board (sensor
connection back section end position)
through the power chain to cable W502
(plug connection in left strut)
Chapter 13.2, page 93
2025265 W203 Cable from the distributor board (sensor
connection to zero position of leg section)
through the power chain to cable W503
(plug connection in left strut)
Chapter 13.2, page 93
2025268 W204 (end
position, zero
position switch)
Cable from the longitudinal slide switches
through the power chain to the distributor
board
Chapter 13.2, page 93
2072485 W220 Cable from the distributor board (hook
sensor connection) through the power
chain to cable W520 (plug connection in
left strut)
Chapter 13.2, page 93
2025262 W301 Cable from the right motor for leg section
hinge and the right motor for back section
hinge through the power chain to cable
W401 (plug connection in the column
head)
Chapter 13.2, page 93
