6.4 Changes in Voltage
95
Scrolling through waveforms
SCROLL
Scroll through the
graph
Scroll bar
Graph display range
All recorded data
The graph display range (white belt) on the scroll bar ind
i-
cates what interval of recorded data is displayed on th
e
screen.
When AUTO is set during recording, the X-axis and Y-axis ar
e
automatically scaled so that all the time series graphs are dis
-
played on the screen.
If you change the X/Y-axis scale, you can scroll through th
e
time series graph in every direction.
Waveform display
range
Cursor position
The cursor on the scroll bar in-
dicates where the cursor is po-
sitioned on the all recorded
data.
Searching for events
Event marker
EVENT JUMP
Skips sideways
through the event
markers.
Analyzing events using
waveforms
Synchronization is achieved with an event selected from th
e
event list.
You can search for the time the event occurred (even
t
marker ).
The start time and stop time event markers are always dis
-
played.
Event marker
(red): Indicates an ordinary event.
(blue): Indicates an event for which an event voltag
e
fluctuation graph is recorded.
