ΔV10 Flicker Text Time-sequence Data-header
Composition
IEC Flicker Text Time-sequence Data-header
Composition
Text Event Waveform Data Format Composition
Text Voltage Fluctuation Event Data Format Composition
Classification Header Explanation Example
Date and
Time
Date Date 2001/11/02
Time Time 17:19:00
ΔV10 dv10 ΔV10 instantaneous value 0.081
max ΔV10 total maximum value 0.158
dv10max ΔV10 maximum value for one hour 0.000
dv10max4 ΔV10
fourth largest value for one
hour
0.000
dv10ave ΔV10 average value for one hour 0.000
Classification Header Explanation Example
Date and
Time
Date Date 2002/3/5
Time Time 15:24:15
Pst, Plt Pst 1 CH1 Pst 0.325
Pst 2 CH2 Pst 0.386
Pst 3 CH3 Pst 0.358
Plt 1 CH1 Plt 0.325
Plt 2 CH2 Plt 0.386
Plt 3 CH3 Plt 0.358
1 2001/11/02 17:19:00 Date, Time
2U
1
I
1
U
2
I
2
U
3
I
3
U
4
I
4
Header
(channel)
3
.
.
3586
or
4098
Measurement
data
1 2001/11/02 17:19:00 Date, Time
2
U
1
U
2
U
3
Header
(channel)
3
.
.
1002
or
1202
Measurement
data
