12.3 Setting Functions
194
12.3 Setting Functions
System Settings
CH1, 2, 3 CH4
Measured line
1P2W, 1P3W, 3P3W2M, 3P3W3M, 3P4W AC, DC, and OFF
Clamp sensor ratings
0.1 mV/A, 1 mV/A, 10 mV/A, 100 mV/A Same as CH1, CH2, and CH3.
Voltage range
150 V, 300 V, 600 V
For AC: 60 V, 150 V, 300 V, 600 V
For DC: 60 V, 600 V
PT ratio
1, 60, 100, 200, 300, 600, 700, 1000, 2000,
2500, 5000, VARIABLE (0.01 to 9999.99)
Same as CH1, CH2, and CH3.
Current range
When using a 0.1 mV/A sensor:
500 A, 5000 A
When using a 1 mV/A sensor:
(9661): 50 A, 500 A
(9660): 50 A, 100 A
When using a 10 mV/A sensor:
(9694): 5 A, 50 A
When using a 100 mV/A sensor:
500 mA, 5 A
When using a 9667 sensor:
(5000 A range): 500 A, 5000 A
(500 A range): 50 A, 500 A
When using a 9669 sensor:
100 A, 1000 A
Same as CH1, CH2, and CH3.
CT ratio
1, 40, 60, 80, 120, 160, 200, 240, 300, 400,
600, 800, 1200, VARIABLE (0.01 to 9999.99)
Same as CH1, CH2, and CH3.
Measured line frequency
50/60 Hz
PLL synchronization/Fre-
quency source
Voltage: U1, U2, U3
Measured RMS voltage
selection
Phase-to-neutral voltage and line-to-line voltage
Measured harmonic selec-
tion
RMS and % of fundamental (content percentage)
Measured harmonic distor-
tion factor selection
THD-F (basic wave standard)/THD-R (total harmonic value standard)
Power factor selection
Power factor/Displacement power factor
Flicker measurement selec-
tion
OFF/Δ V10/ Pst,Plt
Nominal voltage
100/ 101/ 110/ 120/ 200/ 202/ 208/ 220/ 230/ 240/ 277/ 346/ 380/ 400/ 415/
480/ 600/ VARIABLE (50 to 600 V in 1 V increments)
Voltage recording
Urms/ ΔU/ S(t)
Flicker measurement CH
U1 to U3
Filter
120 V lamp/ 230 V lamp
EN50160
ON/ OFF
