37
For details about connection precautions, Refer to the Quick Start Manual.
Connections Chapter 3
Rear
Top view
Before connecting to the
power line that you want to
measure, make sure that you
perform steps 1 to 7.
1. Connecting to the 3196 POWER QUALITY ANALYZER
1
2
3
7
5
6
4
Turn on the 3196.
7
Connect to the power line that you
want to measure. (to the next page)
Connect the clamp sensor.
(Use the input cord label.)
6
Connect the voltage cord.
(Use the input cord label.)
5
Connect the Wiring Adapter (optional)
When not connecting the Wiring Adapter, go
to step
5.
4
Connect the AC adapter and power
cord.
3
Install the battery pack.
2
Attach the Strap.
*If unnecessary, go to step 2.
1
To Next Page
