4.3 Making System Settings
49
4.3.1 Main Settings
4.3 Making System Settings
MAIN
MEASURE
❖ Connection method settings (CH 1, 2, 3) (page 50)
Connection method settings (CH 4) (page 50)
❖ Clamp sensor settings (page 51)
❖ Voltage and current range settings (page 51)
❖ PT and CT ratio settings (page 52)
❖ Nominal voltage settings (page 52)
❖ Measured frequency settings (page 53)
❖ PLL source settings (page 53)
❖ Voltage calculation method settings (page 54)
❖ Harmonic calculation method settings (page 54)
❖ THD calculation method settings (page 55)
❖ Power factor calculation method settings (page 55)
❖ Flicker calculation settings (page 56)
❖ Voltage recording method settings (page 56)
❖ IEC flicker filter settings (page 57)
❖ ΔV10 flicker measurement channel settings (page
57)
❖ EN50160 settings (page 58)
