4.3 Making System Settings
57
IEC flicker filter settings
MEASURE
Filter
Select from pull-
down menu
Confirm
Cancel
100 V lamp, 120 V lamp, 230 V lamp
Select a lamp system filter defined in IEC 61000-4-15.
This setting is available only when “Pst, Plt” is selected for
Flicker.
ΔV10 flicker measurement channel settings
MEASURE
Flicker CH
Select from pull-
down menu
Confirm
Cancel
U1, U2, U3
ΔV10 flicker can only be measured on one of channels U1, U2
or U3.
This setting is available only when
ΔV10 is selected for Flicker.
