12.2 Measurement Specifications
193
Power Range Configuration Tables
Applies to the active power of each channel (unit W), apparent power (unit VA), and reactive power
(unit var).
When using a 0.1 mV/A (5000A) sensor
When using a 1 mV/A (500A) sensor or
9661 sensor
Current range
Voltage range
500.00 A 5000.0 A
Current range
Voltage range
50.000 A 500.00 A
150.00 V 75.000 k 750.00 k 150.00 V 7.5000 k 75.000 k
300.00 V 150.00 k 1.5000 M 300.00 V 15.000 k 150.00 k
600.00 V 300.00 k 3.0000 M 600.00 V 30.000 k 300.00 k
When using a 9660 sensor
When using a 10 mV/A (50A) sensor or
9694 sensor
Current range
Voltage range
50.000 A 100.00 A
Current range
Voltage range
5.0000 A 50.000 A
150.00 V 7.5000 k 15.000 k 150.00 V 750.00 7.5000 k
300.00 V 15.000 k 30.000 k 300.00 V 1.5000 k 15.000 k
600.00 V 30.000 k 60.000 k 600.00 V 3.0000 k 30.000 k
When using a 100 mV/A (5A) sensor When using a 9667 sensor 5000A range
Current range
Voltage range
500.00 mA 5.0000 A
Current range
Voltage range
500.00 A 5.0000 kA
150.00 V 75.000 750.00 150.00 V 75.000 k 750.00 k
300.00 V 150.00 1.5000 k 300.00 V 150.00 k 1.5000 M
600.00 V 300.00 3.0000 k 600.00 V 300.00 k 3.0000 M
When using a 9667 sensor 500A range When using a 9669 sensor
Current range
Voltage range
50.000 A 500.00 A
Current range
Voltage range
100.00 A 1.0000 kA
150.00 V 7.500 k 75.000 k 150.00 V 15.000 k 150.00 k
300.00 V 15.000 k 150.00 k 300.00 V 30.000 k 300.00 k
600.00 V 30.000 k 300.00 k 600.00 V 60.000 k 600.00 k
Event Specifications
Event contents
Various events, measurement start, measurement stop
Event detection method
Detects events with OR.
Measurement used for
event detection
Interruption values of measurements (Inter-harmonics detection is not pos-
sible.) (Event detection for MAX, MIN, and AVE values is not possible.)
