Hioki 3196 - Page 201

12.3 Setting Functions
195
Hardware Settings
Display language
English, German, French, Italian, Spanish, Japanese
Beep
ON/ OFF
Screen colors
COLOR 1 to 4, MONO
LCD backlight
ON/ Auto OFF (I m, 5 m, 10 m, 30 m, 1 h)
Real-time settings
Year/month/day/hour/minute
System reset
You can reset the unit to its defaults with the system's reset procedure.
(This does not reset the display language, clock, IP address, or subnet
mask.)
Version information
Software version display
Timer interval
OFF, 1 m, 5 m, 10 m, 30 m, 1 h, 2 h
Timer
OFF/COPY/EVENT
Measurement Time Control Settings
Real time control
OFF (Manual) / ON (time settings)
Start and end time settings
year/month/day/hour/minute (24-hour clock)
Time Series Data Settings
Interval settings
1 s, 3 s, 15 s, 30 s, 1 m, 5 m, 10 m, 30 m, 1 h, 2 h
MAX/MIN/AVE settings
AVE value/(MAX value, MIN value, AVE value)
Recorded item settings
Pattern 1, Pattern 2, Pattern 3
1: Power/ 2: P&Harm/ 3: ALL DATA
Recorded item Pattern
123
Voltage (one wave shifted
over half a wave)
● ● ●
Frequency
●●●
RMS voltage value
● ● ●
RMS current value
●●●
Voltage waveform peak
● ● ●
Current waveform peak
●●●
Active power
● ● ●
Apparent power
●●●
Reactive power
● ● ●
Power factor/Displacement
power factor
●●●
Voltage unbalance factor
● ● ●
Current unbalance factor
●●●
1: Power/ 2: P&Harm/ 3: ALL DATA
Recorded item Pattern
123
Harmonic voltage
×
● ●
Harmonic current
×
●●
Harmonic power
×
● ●
Harmonic voltage-current
phase difference
×
●●
Inter-harmonic voltage
× ×
●
Inter-harmonic current
××
●
Total harmonic voltage distor-
tion factor
● ● ●
Total harmonic current distor-
tion factor
●●●
Total inter-harmonic voltage
distortion factor
× ×
●
Total inter-harmonic current
distortion factor
××
●
K factor
● ● ●
Flicker (Δ V10 or Pst, PLt)
●●●
