12.3 Setting Functions
196
Data Save Settings (save methods for time series data and event data)
Data save area
Always saves data in the internal memory (when a PC card is connected,
saves data on the PC card as well)
Settings when the data save
area is full
STOP/ LOOP
(When “LOOP” is set: Time series data in internal memory: first in first out,
event data: the worst event data is overwritten)
External Interface Settings
RS-232C output point
printer/modem/OFF (The LAN may be used when modem is not set as the
output point.)
RS-232C settings
Baud rate (bps): 9600, 19200, 38400, 57600, 115200
(Other settings are fixed, transfer method: asynchronous communication
method, data length: 8 bits, parity check: none, stop bit: 1, flow control:
off, delimiter: CR + LF)
Modem setting
Modem communication monitoring time: OFF/ 1min/ 5min/ 10min/ 30min
LAN settings
IP address: 3 characters.3 characters.3 characters.3 characters
(***.***.***.***)
Subnet mask: 3 characters.3 characters.3 characters.3 characters
(***.***.***.***)
PC Card Settings
Auto-save settings
OFF, BINARY, TEXT
PC card access function
Load (BINARY only), Save (BINARY or TEXT), Delete, Initialize
TEXT content setting
Fundamental, power, and channel settings.
Harmonics, maximum order number, and channel settings.
Repeated Recording Settings
Repeated recording settings OFF/ 1 day/ 1 week
The number of repeated
recording operations
1 to 99 times
Repeated recording function operable when MemoryFull: LOOP, Auto Saves: Binary, and Time-
Start: ON.
