Appendix
225
RMS val-
ue fluctua-
tion
Average
value
AveFreq Frequency
AveUrms1,...,AveUrms4 RMS voltage value
CH1 - CH4
AveU+peak1,...,AveU+peak4 Voltage waveform peak (+)
CH1 - CH4
AveU-peak1,...,AveU-peak4 Voltage waveform peak (-)
CH1 - CH4
AveIrms1,...,AveIrms4 RMS current value
CH1 - CH4
AveI+peak1,...,AveI+peak4 Current waveform peak (+)
CH1 - CH4
AveI-peak1,...,AveI-peak4 Current waveform peak (-)
CH1 - CH4
AveUave Average RMS voltage value
ave
AveIave Average RMS current value
ave
AveP1,...,AveP3 Active power
CH1 - CH3
AvePsum Sum of active power
sum
AveS1,...,AveS3 Apparent power
CH1 - CH3
AveSsum Sum of apparent power
sum
AveQ1,...,AveQ3 Reactive power
CH1 - CH3
AveQsum Sum of r eactive power
sum
AvePF1,...,AvePF3 Power factor/Displacement power factor
CH1 - CH3
AvePFsum Sum of Power factor/Displacement power
factor
sum
AveKF1,...,AveKF4 K factor
CH1 - CH4
AveUunb Voltage unbalance factor
AveIunb Current unbalance factor
AveUthd1,...,AveUthd4 Total harmonic voltage distortion factor
CH1 - CH4
AveIthd1,...,AveIthd4 Total harmonic current distortion factor
CH1 - CH4
AveU1(1),...,AveU4(50) Harmonic voltage
CH1 - CH4 1st - 50th
AveI1(1),...,AveI4(50) Harmonic current
CH1 - CH4 1st - 50th
AveP1(1),...,AveP3(50) Harmonic power
CH1 - CH3 1st - 50th
AvePhase1(1),...,AvePhase3(50) Harmonic voltage-current phase difference
CH1 - CH3 1st - 50th
AvePsum(1),...,AvePsum(50) Harmonic power
sum 1st - 50th
AvePhasesum(1),...,AvePhase-
sum(50)
Harmonic voltage-current phase difference
sum 1st - 50th
AveUtihd1,...,AveUtihd4 Total harmonic voltage distortion factor
CH1 - CH4
AveItihd1,...,AveItihd4 Total harmonic current distortion factor
CH1 - CH4
AveU1(0.5),...,AveU4(49.5) Inter-harmonic voltage
CH1 - CH4 0.5 - 49.5th
AveI1(0.5),...,AveI4(49.5) Inter-harmonic current
CH1 - CH4 0.5 - 49.5th
Classifica-
tion
Header Explanation
