Appendix
224
RMS val-
ue fluctua-
tion
Minimum
value
MinFreq Frequency
MinUrms1,...,MinUrms4 RMS voltage value
CH1 - CH4
MinU+peak1,...,MinU+peak4 Voltage waveform peak (+)
CH1 - CH4
MinU-peak1,...,MinU-peak4 Voltage waveform peak (-)
CH1 - CH4
MinIrms1,...,MinIrms4 RMS current value
CH1 - CH4
MinI+peak1,...,MinI+peak4 Current waveform peak (+)
CH1 - CH4
MinI-peak1,...,MinI-peak4 Current waveform peak (-)
CH1 - CH4
MinUave Average RMS voltage value
ave
MinIave Average RMS current value
ave
MinP1,...,MinP3 Active power
CH1 - CH3
MinPsum Sum of active power
sum
MinS1,...,MinS3 Apparent power
CH1 - CH3
MinSsum Sum of apparent power
sum
MinQ1,...,MinQ3 Reactive power
CH1 - CH3
MinQsum Sum of r eactive power
sum
MinPF1,...,MinPF3 Power factor/Displacement power factor
CH1 - CH3
MinPFsum Sum of Power factor/Displacement power
factor
sum
MinKF1,...,MinKF4 K factor
CH1 - CH4
MinUunb Voltage unbalance factor
MinIunb Current unbalance factor
MinUthd1,...,MinUthd4 Total harmonic voltage distortion factor
CH1 - CH4
MinIthd1,...,MinIthd4 Total harmonic current distortion factor
CH1 - CH4
MinU1(1),...,MinU4(50) Harmonic voltage
CH1 - CH4 1st - 50th
MinI1(1),...,MinI4(50) Harmonic current
CH1 - CH4 1st - 50th
MinP1(1),...,MinP3(50) Harmonic power
CH1 - CH3 1st - 50th
MinPhase1(1),...,MinPhase3(50) Harmonic voltage-current phase difference
CH1 - CH3 1st - 50th
MinPsum(1),...,MinPsum(50) Harmonic power
sum 1st - 50th
MinPhasesum(1),...,MinPhase-
sum(50)
Harmonic voltage-current phase difference
sum 1st - 50th
MinUtihd1,...,MinUtihd4 Total harmonic voltage distortion factor
CH1 - CH4
MinItihd1,...,MinItihd4 Total harmonic current distortion factor
CH1 - CH4
MinU1(0.5),...,MinU4(49.5) Inter-harmonic voltage
CH1 - CH4 0.5 - 49.5th
MinI1(0.5),...,MinI4(49.5) Inter-harmonic current
CH1 - CH4 0.5 - 49.5th
Classifica-
tion
Header Explanation
