7.4 Event List Display
129
About the event list sequence
Time order Example: When 35 events have occurred
No.1 Dip CH1 OUT ............ Indicates the event that occurred last.
(Events ended with occurrence of a voltage
dip.
No.35 Start ...........................Indicates the event that occurred first. (Start
event occurred.
Priority order Example: When 100 or more events have occurred
No.1 Dip CH1 OUT ............Indicates the highest priority. (Events ended
with occurrence of a voltage dip.
No.100 Wave CH1 .................Indicates an event with low priority. (Voltage
waveform distortion occurred.
About the event list display contents
List display Example: 96 06-16 12:47:58:253 U_THD CH1 IN
96..............................................Sequence number
06-16......................................... Month - Day
12:47:58:253.............................Hour:minute:second:1/1000th sec
U_THD...................................... Total voltage distortion factor.
CH1........................................... Channel 1
IN ..............................................Measurement start and end times
Details display Example: 2001/6/16 12:48:06.845 Swell CH1 OUT 108.52V 0:00:04.642
2001/6/16..................................Year/Month/Day
12:48:06.845.............................Hour:minute:second:1/1000th sec
Swell .........................................Voltage swell
CH1........................................... Channel 1
OUT ..........................................End of occurrence
108.52V ....................................The worst value
0:00:04.642...............................Time from start of occurrence to end of occur-
rence
