11.2 Control and Monitoring Using a LAN Interface
171
Example of a network environment structure
Example 1: Connecting the 3196 to an existing network
When you connect the 3196 to an existing network, the system administrator must make the set-
tings beforehand.
Make sure that the settings are unique to this device.
Note the following settings assigned by your system administrator.
IP address ___.___.___.___
Subnet mask ___.___.___.___
Example 2: Connecting several 3196 units to a single PC through a hub
When assembling a isolated local network, it is recommended that you use private IP addresses.
When assembling the network with the network address 192.168.1.0/24:
IP address ....................... PC: 192.168.1.1
This device: Add in the following order: 192.168.1.2, 192.168.1.3,
192.168.1.4, and so on.
Subnet mask ................... 255.255.255.0
Example 3: Connecting the 3196 locally to a PC using the 9642 LAN CABLE
When connecting the 3196 locally to a PC using the connector supplied with the 9642 LAN
CABLE, you can set the desired IP address, but we recommend that you use a private IP
address.
IP address ....................... PC: 192.168.1.1
This device: 192.168.1.2 (Set the IP address to a different value.)
Subnet mask ................... 255.255.255.0
