2.2 Screen Names and Configurations
18
RMS
❖ 6.3 "Changes in RMS
Value"(page 89)
1 ELEMENT
You can select one measurement
item and display RMS time series
graphs for each measurement inter-
val of 200 ms.
2 ELEMENT
You can select two measurement
items and display RMS time series
graphs for each measurement inter-
val of 200 ms.
VOLTAGE
❖ 6.4 "Changes in Volt-
age"(page 93)
INTERVAL
Displays a time series graph for the
voltage measured in one waveform
shifted over half a wave for each
measurement interval.
EVENT
Displays a half cycle-shifted, 10-sec-
ond time series graph for a voltage
event in a single waveform.
HARMONICS
❖ 6.5 "Changes in Harmon-
ics"(page 100)
HARM
You can select 6 orders and display
it in a harmonics time series graph.
INTERHARM
You can select 6 orders and display
the inter-harmonics.
FLICKER
❖ 6.6 "Flicker"(page 104)
GRAPH
Displays a time series graph for IEC
flicker or
ΔV10 flicker.
LIST Displays a list of IEC flicker or ΔV10
flicker statistics.
TIME PLOT Screen
To Next Page
