2.2 Screen Names and Configurations
35
Sets the wiring, voltage range, PT ra-
tio, nominal voltage, and thresholds of
transient, swell, dip, and interruption, in
accordance with the EN50160.
Setting1
EN50160 EVENT Screen
Sets the thresholds of frequency, volt
age fluctuation, flicker, unbalance fac-
tor, THD, signaling voltage, in
accordance with the EN50160.
Setting2
Sets the thresholds of harmonic wave
form, in accordance with the EN50160
Setting3
EN50160 display is not available when measuring 400 Hz.
