12.2 Removing the Battery Before Discarding the Unit
______________________________________________________________________________________________
Cover
Front panel
12.2 Removing the Battery Before Discarding the Unit
The 8730-10, 8731-10 uses a lithium battery for memory backup.
When disposing of this instrument, remove the lithium battery and dispose
of battery and instrument in accordance with local regulations.
1. Confirm that power of the 8730-10, 8731-10 is turned OFF.
2. Disconnect all cables and the power cord from the 8730-10, 8731-10.
3. Use a Phillips screwdriver to remove the seven screws below, then remove
the cover.
4.Remove the four screws below, then remove the front panel.
To Next Page
