4.3 Details of Input Setting
______________________________________________________________________________________________
4.3.10 Entering Channel Comments
Setting Screen: Unit CH1 (CH2)
Comment
NOTE
Allows you to enter a comment for each channel.
The comment is displayed when "
Comment
" is selected for the "
Info
(Upper)" setting.
Setting Procedure
1. Press the
DISPLAY
key and use the right
and left
CURSOR
keys to select the
"
Unit
"tag.
2. Select the channel to set, then press the
ENTER
key.
(Note 1)
3. Select "
Comment
", then press the
ENTER
key.
4. Enter a comment. For how to enter
comments, see 8 in 3.1.2.
(Note 1) Channel selection is not possible
with the 8730-10.
Up to sixteen characters can be entered.
