8.3 Multiplexer Settings
157
8
Setting basic measurement conditions
1
Open the Settings Screen.
2
Open the Multiplexer Basic Measurement Screen.
3
Move to the channel you wish to set.
<Hint>
You can copy the settings for the selected channel to the next channel with the
key. (All settings shown on the screen as well as those on the [MEAS] tab will
be copied.)
You can return to the [MUX1] tab with the key.
The Settings screen
appears.
Switch the function menu
to P.2/3.
1
2
Move the cursor to the
[MUX2] tab with the left and
right cursor keys.
Select the channel to set.
To Next Page
