Servo Drive Configuration E1 Series Servo Drive Thunder Software Operation Manual
4-50 HIWIN MIKROSYSTEM CORP.
4.4.2.2 Set Pt parameters
Servo drive Pt parameters are classified into eight categories, Pt0XX to Pt7XX. Each parameter can be
classified as setup parameter or tuning parameter. Users can set the related Pt parameters based on the
category.
Table 4.4.2.2.1
Parameters for setting basic function
Position-related parameters
Velocity-related parameters
Torque-related parameters
Parameters for I/O setting
Parameters for regenerative resistor setting
Parameters for internal homing
Figure 4.4.2.2.1
Follow the procedure below to set Pt parameters.
1. Double-click Pt parameter’s Modified Value column to open parameters modifying window.
Figure 4.4.2.2.2
2. Modify the parameter and press Enter key on the keyboard.
To Next Page
