Servo Drive Configurat
ion
E1 Series Servo Dr
ive Thunder Software Operati
on Manual
4-
60
HIWIN MIKROSYST
EM CORP
.
MD12UE01-
2012
4.4.3.3
Load servo drive parameters file (*.prm)
DANGER
◆
To avoid unexpected act
ions, ensure the
motor is disa
bled and remains
static before execut
ion.
Follow the procedu
re below to load
the created s
ervo drive pa
rameters fil
e to servo drive.
1.
Click “Load parame
ters from file
to drive” icon to
open “Load prm fil
e” windo
w
.
Figure 4.4.3.3.1
2.
Click
.
Figure 4.4.3.3.2
123
125
