E1 Series Servo Drive Thunder Software Operation Manual Monitoring
HIWIN MIKROSYSTEM CORP. 7-27
MD12UE01-2012
7.5.6 Start or pause waveform monitoring
Follow the procedure below to start or pause waveform monitoring.
1. Click to start waveform monitoring.
Figure 7.5.6.1
2. Waveform monitoring starts.
Figure 7.5.6.2
