Hiwin E1 Series - Application Function

E1 Series Servo Drive Thunder Software Operation Manual Servo Drive Configuration
HIWIN MIKROSYSTEM CORP. 4-67
MD12UE01-2012
4.4.6.2 Set to factory default
Follow the procedure below to restore servo drive parameters.
Information
The default of Disable multi-motion function option is checked.
1. Select Tools in the menu bar, and click Set to factory default.
Figure 4.4.6.2.1
2. Uncheck Disable multi-motion and click Ok to restore servo drive parameters.
Figure 4.4.6.2.2
