Hiwin E1 Series - Full-Closed Loop Function

Monitoring E1 Series Servo Drive Thunder Software Operation Manual
7-14 HIWIN MIKROSYSTEM CORP.
MD12UE01-2012
◼ Off
1. Click Off to close waveform display.
Figure 7.3.1.1.8
2. Click On to activate waveform display.
Figure 7.3.1.1.9
