11.1 Examples for servo drive configuration
This section takes three different kinds of motors for example:
◆ HIWIN self-made AC servo motor (EM1 series)
◆ HIWIN self-made DM direct drive motor (RM series)
◆ Linear motor
Refer to chapter 4 for more detailed descriptions of servo drive configuration.
AC servo motor (EM1 series)
With EM1 series motor, Thunder will automatically fill in motor parameters. This section demonstrates the
operation of servo drive configuration with AC servo motor (EM1 series).
DM direct drive motor (RM series)
With RM series motor, Thunder will automatically fill in motor parameters after users complete pre-
configuration function setting. This section demonstrates the operation of servo drive configuration with
DM direct drive motor (RM series).
Linear motor
With linear motor, users must select motor parameters. This section demonstrates the operation of servo
drive configuration with linear motor.
